Product Focus | New 2"-5" Transflective TFTs: Impeccable Visibility

Product Focus | New 2"-5" Transflective TFTs: Impeccable Visibility

In today’s landscape, where electronic devices are expected to deliver consistent performance across very different environments, display readability is a critical factor. An HMI module may be required to operate both in a dimly lit control room and under direct sunlight. Transflective TFT technology has been developed to address precisely this challenge: it combines the transmissive mode, based on backlighting, with the reflective mode, which leverages ambient light. The result is excellent visibility under any lighting condition, along with optimized power consumption.

Thanks to this approach, transflective displays represent an ideal solution for portable applicationsoutdoor instrumentationwearable devices and automotive systems, where clarity, reliability, and low power consumption are non-negotiable requirements.

FIRST Components is now expanding its portfolio by introducing three new transflective modules from Winstar.

These modules combine robustnessefficiency and readability, ensuring consistent performance even in the most demanding environmental conditions.



Compact Sizes for Wearable and Portable Devices

WFN0200DA2#000-FC
TFT 2" 240x320 Portrait Transflective LCD Panel



🔹 Size: 2 inches
🔹 Resolution: 240x320
🔹 Module Dimension: 35.8x52.1x2.65 mm
🔹 Active Area: 30.60x40.80 mm
🔹 View Angle: 80/80/80/80 (VA)
🔹 Interface: MCU/SPI+RGB
🔹 Driver IC: ST7789
🔹 Brightness: 260 cd/m²
🔹 Operating Temperature: -20~+70°C



WFN0240DA2#0X0-FC
TFT 2.4" 240x320 Portrait Transflective LCD Panel


                  🔹 Size: 2.4 inches
                  🔹 Resolution: 240x320
                  🔹 Module Dimension: 42.72x 60.26x2.63 mm
                  🔹 Active Area: 36.72x48.96 mm
                  🔹 View Angle: 3H
                  🔹 Interface: MCU/SPI+RGB
                  🔹 Driver IC: ST7789
                  🔹 Brightness: 250 cd/m²
                  🔹 Operating Temperature: -20~+70°C




Medium Size with Wide Viewing Angle and High Resolution

WFN0500DA2#000-FC
TFT 5" 800x480 Transflective LCD Panel



🔹 Size: 5 inches
🔹 Resolution: 800x480
🔹 Module Dimension: 120.8x75.9x2.73 mm
🔹 Active Area: 108.0x64.8mm
🔹 View Angle: IPS
🔹 Interface: RGB
🔹 Brightness: 200 cd/m²
🔹 Operating Temperature: -30~+85°C




For more technical information contact us at [email protected].
To request a dedicated quote for your project, reach out to our experienced sales team
at [email protected].
