NT070-C002DW

Immagine di NT070-C002DW Immagine di NT070-C002DW
TFT 7" 1024x600 LCD Panel, Interface RGB, 250cd/m², Wide View Angle (IPS), Capacitive touch panel I2C interface (GG, GT911 IC)

General Specification

Color 16.7M
LCD Type IPS-TFT-LCD
Viewing Angle Wide viewing angle, 80/80/80/80(L/R/U/D)
Display Area(A.A) 154.21(W)*85.92(H)
Driver IC HX8282-A11DPD300+HX8696-A01APD300
EK79001HK + EK73215BCGA
Luminance 250cd/m²
LED Numbers 21 LEDS
Interface RGB_24bit 50PIN_0.5mm



Electrical Characteristics

Digital Voltage 3.3V(Typ.)
Forward Voltage 9.3V(Typ.)
Forward Current 140mA
Uniformity(with L/G) 80%



Optical Characteristics

Contrast Ratio 1000:1
Response Time ON=10ms, OFF=15ms



General Specification

Feature Description
Type CTP (Capacitive touch panel)
Structure G+G
Outline Size (mm) 164.6(L)*99.7(W)*1.6(T)
View Area (mm) 154.08(L)*85.92(W)
Control Type GT911
Surface hardness 6H
Light Transmittance ≥85%
Operating Temperature -10~60°C
Storage Temperature -20~70°C





DRAWING

SKU: NT070-C002DW
Brand: Next Vision Display
Disponibile: Si
Si tratta dela prima recensione per questo prodotto
Kit Accessori
Prezzi per quantità
Quantità
1+
5+
10+
Prezzo
€29,30
€25,30
€22,70

Per quantita’ maggiori di 25pz prego invii la richiesta a [email protected] o chiami il +39 0332 1888005

€29,30 IVA esclusa

General Specification

Color 16.7M
LCD Type IPS-TFT-LCD
Viewing Angle Wide viewing angle, 80/80/80/80(L/R/U/D)
Display Area(A.A) 154.21(W)*85.92(H)
Driver IC HX8282-A11DPD300+HX8696-A01APD300
EK79001HK + EK73215BCGA
Luminance 250cd/m²
LED Numbers 21 LEDS
Interface RGB_24bit 50PIN_0.5mm



Electrical Characteristics

Digital Voltage 3.3V(Typ.)
Forward Voltage 9.3V(Typ.)
Forward Current 140mA
Uniformity(with L/G) 80%



Optical Characteristics

Contrast Ratio 1000:1
Response Time ON=10ms, OFF=15ms



General Specification

Feature Description
Type CTP (Capacitive touch panel)
Structure G+G
Outline Size (mm) 164.6(L)*99.7(W)*1.6(T)
View Area (mm) 154.08(L)*85.92(W)
Control Type GT911
Surface hardness 6H
Light Transmittance ≥85%
Operating Temperature -10~60°C
Storage Temperature -20~70°C





DRAWING

Specifiche di prodotto
Brand Next Vision Display
Size 7"
Risoluzione 1024x600
Area Attiva (mm) 154.21x85.92
Colore Full Color
Interfaccia Display RGB
Display IC No
Angolo Visione IPS
Frame No
Touch Panel Capacitive
Temperatura O. (°C) -20~70
Connessione Display FPC for ZIF Connector
Nr. Pin 50
Passo Pin 0.5mm
IC Controller Touch Panel GT911
Preferred - Not Preferred Preferred
Download
Specifiche di prodotto
Brand Next Vision Display
Size 7"
Risoluzione 1024x600
Area Attiva (mm) 154.21x85.92
Colore Full Color
Interfaccia Display RGB
Display IC No
Angolo Visione IPS
Frame No
Touch Panel Capacitive
Temperatura O. (°C) -20~70
Connessione Display FPC for ZIF Connector
Nr. Pin 50
Passo Pin 0.5mm
IC Controller Touch Panel GT911
Preferred - Not Preferred Preferred
