WL0F0007000A8GDADSA00-FC

TFT 7" 1024x600, RS485 Modbus interface & GPIO Support, 450cd/m², Wide View Angle (IPS), Capacitive touch panel (GG)

DESCRIPTION

    Link to 'SMART GUI BUILDER' INTRODUCTION & VIDEO

7 Inch Smart Display (RS485 series) Features

  • +12V power supply input with 8V to 35V dynamic range power input, the power consumption is around 6 Watt.
  • Self-testing after booting function.
  • RS485 communication interface.
  • Built in 16MB external flash memory to store the font and Object Dictionary  Data.
  • Support capacitive touch panel (CTP).
  • Build in buzzer and can be controlled by Master Device.
  • Demo set HOST can be used on multiple platforms, such as Computer (with USB to RS485 Dongle), MCU, Raspberry Pi.
  • GPIO PIN support with 3.3V TTL.



DRAWING

SPECIFICATIONS

General Specifications

ItemStandard ValueUnit
Operating voltage 8V~35V dynamic Vdc
Communication Interface RS485 -
MCU STM32F746 N/A
Flash Memory 16 MB
LCD display size 7 inch
Pixel pitch 1024 x RGB x 600(TFT) dots
Module dimension 184.1(W) x 103.8(H) x 22(D) mm
Active area(AA) 154.2144 x 85.92 mm
Pixel pitch 0.1506 x 0.1432 mm
Brightness Min:400; Typ:450 cd/m2
LCD type TFT, Normally Black, Transmissive
Viewing Angle 85/85/85/85
Aspect Ratio 16:9
Touch Panel With CTP
Surface Glare



Absolute Maximum Ratings

ItemSymbolMinTypMaxUnit
Operating Temperature TOP -20 +70
Storage Temperature TST -30 +80



Electrical Characteristics

ItemSymbolConditionMinTypMaxUnit
Supply Voltage VIN 5 12 35 V
Supply current I(mA) - 520 - mA



BOM

ItemDescription
LCM

WF70‐1024600A8L#BP3‐FC

PCBA SV10007R00A8K00N0105



Interface Pin Function

CON2 definition

PinSymbolFunctionRemark
1 Reserve _ _
2 Reserve _ _
3 Reserve _ _
4 Reserve _ _
5   Reserve _ _
6 Reserve _ _
7 Reserve _ _
8 Reserve _ _
9 NC _ _
10 Reserve _ _
11 Reserve _ _
12 Reserve _ GND
13 VIN Power supply V+ Input
14 RS485_B RS485 B I/O
15 RS485_A RS485 A I/O
16 GND Power supply GND input _


CON3 definition

PinSymbolFunctionRemark
1 +3V3 3.3V power for JTAG interface Output
2 SWCLK CLK pin for JTAG interface Input
3 GND GND for JTAG interface Output
4 SWDIO Data pin for JTAG interface I/O
5 NRST Reset pin for JTAG interface Input
6 GND Power GND Output
7 Wkup Wkup, ADC, Timer, Event, I/O Input
8 BOOT0 Lo: Internal flash boot (Default)
Hi: external flash boot
Input
9 IO_0 ADC,DAC,Timer,Event,I/O @3.3V PA5
10 IO_1 ADC,Timer,Event,I/O @3.3V PA6
11 IO_2 ADC,Timer,Event,I/O @3.3V PA7
12 IO_3 ADC,Timer,Event,I/O @3.3V PA8
13 IO_4 ADC,Timer,Event,I/O @3.3V PC13
14 IO_5 ADC,Timer,Event,I/O @3.3V PB11
15 IO_6 ADC,Timer,Event,I/O @3.3V PA15
16 IO_7 RST,ADC,Event,I/O @3.3V PD11


Display Usage

Functional description

Smart Display can be used to display the coordinate, status and data information provided by the connected HOST device. Customers can configure the position coordinates they want to display in normal operation mode.

The Display is designed to be easily connected to a controller network, and to use the register type of Holding Register

Splash Screen

The default splash image is shown below.

This product is produced as a generic product. If you require a custom splash image for your application, contact us to discuss.

Acquisition of Displayed Data

Smart Display uses the Modbus protocol to get and send the data.

On Config mode, customers can set the coordinates or type of objects; On Display mode, customers can send and get data of objects.

Configuring the Display

Winstar Smart Display RS-485 series offers an out-of-the-box Modbus development experience that will lower customers' development costs and speed time-to-market expectations.

The Smart Display can use wide-temperature are designed to support control applications in harsh operating conditions, which designed to be connected to a variety of different situation combinations, such as automotive, marine, power generation and oil-and-gas.

The Smart Display can use wide-temperature are designed to support control applications in harsh operating conditions, which designed to be connected to a variety of different situation combinations, such as automotive, marine, power generation and oil-and-gas.

The Smart Display comes with standard UI objects to get customers project off the ground quickly. If customers need custom UI objects support, our engineers are here to help. Send over your contents in PNG/JPG format, we will send over a new set of UI objects within 3~5 working days

The Smart Display is defined as a slave device, which is controlled by master device via RS-485 command to render display content on the display screen and return touch event data with protocol objects.

Example Screen Layout (Industry application)

The screen layout described in this section is intended to demonstrate the settings of screen items that can be used in a industry application situation.

Example Screen Layout (Vehicle automotive)

The screen layout described in this section is intended to demonstrate the settings of screen items that can be used in a vehicle automotive situation.

Example Screen Layout (Medical application)

The screen layout described in this section is intended to demonstrate the settings of screen items that can be used in a Medical application situation.

EVALUATION KIT

Evaluation Kit P/N WWSSDEMO70A8-DA-11#002 available at the links:

ITA: https://www.first-components.com/it/wwssdemo70a8-da-11002

ENG: https://www.first-components.com/en/wwssdemo70a8-da-11002

SKU: WL0F0007000A8GDADSA00-FC
Brand: Winstar
Available: No
Accessory Kit
Price Breaks
Quantity
1+
5+
10+
Price
€102.00
€97.00
€91.90

For quantities above 25 pcs pls send your enquiry to [email protected] or call +39 0332 1888005

€102.00 excl tax
