Item |
Min. |
Typical |
Max. |
Unit |
Description |
Operation Voltage |
1.75 |
3.3 |
3.6 |
V |
VBATT |
Imax |
|
|
400 |
mA |
Maximum Current consumption in TX mode |
IPmax |
|
|
500 |
mA |
Peak current rating for power supply |
WLAN Data Transfer Average Current |
|
270 |
|
mA |
11Mbps Tx |
WLAN Data Receive Average Current |
|
48.2 |
|
mA |
72 Mbps Rx |
BR/EDR TX Active Current, 3 Mbps EDR |
|
140 |
|
mA |
HP chain, Tx Power = Maximum |
BR/EDR RX Active Current, 3 Mbps EDR |
|
26.7 |
|
mA |
HP chain |
BLE TX Active Current |
|
190 |
|
mA |
HP Chain, Tx Power = Maximum (20 dBm) |
BLE RX Active Current |
|
26.7 |
|
mA |
HP chain |
WLAN Standby Associated Mode Current |
|
119 |
|
uA |
DTIM=3 Cisco Aironet AP |
WLAN Standby Associated Mode Current |
|
51 |
|
uA |
DTIM=10 Cisco Aironet AP |
Quiescent current |
|
3 |
|
nA |
|
Baud Rate |
9600 |
115200 |
921600 |
bps |
|
Wireless Protocols |
|
|
|
|
IEEE 802.11b, 802.11g, 802.11n
Bluetooth 5 (2.1+EDR, LE, LE 2 Mbp)
|
Operational Modes Supported |
|
|
|
|
Wi-Fi Access Point with support for
up to 16 clients
Wi-Fi Client
Wi-Fi Direct
Bluetooth Classic (EDR v 2.1)
Wi-Fi Client + Bluetooth Low Energy
|
Receive Power |
|
|
10 |
dBm |
|
WLAN Modulation |
|
|
|
|
OFDM with BPSK, QPSK, 16-QAM, and 64-QAM
802.11b with CCK and DSSS
|
WLAN Operating Frequency |
2.412 |
|
2.484 |
GHz |
|
WLAN Bandwidth |
|
20/40 |
|
MHz |
|
WLAN Data Rates |
1
6
|
|
11
54
|
Mbps |
802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n: MCS0 to MCS7
|
Bluetooth Channel Spacing |
1 |
|
2 |
MHz |
BR, EDR, – 1 MHz
LE – 2 MHz
|
