P05DA0075-00

Panel PC 10.1" 1280x800, CPU NXP i.MX8M mini, Memory 2GB LPDDR4, Storage 8GB eMMC Flash, High Brightness 800 cd/m², I/O Interface: USB/LAN/WiFi/BT/Audio, Capacitive touch panel

DRAWING

SPECIFICATIONS

General Specification

Hardware
CPU	RISC Processor	i.MX 8M Mini (Quad Cortex-A53)
Memory	On Board RAM	2GB LPDDR4 SDRAM
Memory	On Board Flash	8GB eMMC Flash
Display	Resolution	1280 x 800 (RGB) DOTS
	Screen Size	10.1 inch
	Display Mode	Transmissive, Normally Black
	Touch Type	Projective Capacitive Touch Panel
Functions	USB	1 x USB OTG 2 X USB 2.0 Host
	Ethernet	10/100/1000 Mbps
	Wireless	WIFI IEEE 802.11 a/b/g/n/ac Bluetooth Antenna
	Switch	Power Button
Power Input	DC	9V~24V

Absolute Maximum Ratings

Parameter	Symbol	Condition	Min	Max	Unit
Power Supply	VIN	-	-0.3	26.0	V
Operating Temperature(TS)	T_OP	-	0	+70	°C
Storage Temperature (TA)	T_ST	-	-30	+80	°C
Humidity	Hd	Ta=60°C	10	90	%RH

Electronical Characteristics

Item	Symbol	Condition	Min	Typ	Max	Unit
Power Supply Voltage	VIN	-	9	12	24	V
Power Supply Current	IIN1	VIN=12V	-	TBD	-	A
IO High-Level input voltage	VIH	-	0.7xVdd3v3	-	Vdd3v3+0.3	V
IO Low-Level input voltage	VIL	-	-0.3	-	0.3xvdd3v3	V
IO High-Level output voltage	VOH	-	-	-	3.6	V
IO Low-level output voltage	VOL	-	-0.3	-	-	V

SKU: P05DA0075-00

Brand: Powertip

Available: No

Be the first to review this product

Price Breaks

Quantity

Price

€314.30

€304.30

For quantities above 25 pcs pls send your enquiry to [email protected] or call +39 0332 1888005

€314.30 excl tax

Overview
Specifications
Download
Contact Us

DRAWING

SPECIFICATIONS

General Specification

Hardware
CPU	RISC Processor	i.MX 8M Mini (Quad Cortex-A53)
Memory	On Board RAM	2GB LPDDR4 SDRAM
Memory	On Board Flash	8GB eMMC Flash
Display	Resolution	1280 x 800 (RGB) DOTS
	Screen Size	10.1 inch
	Display Mode	Transmissive, Normally Black
	Touch Type	Projective Capacitive Touch Panel
Functions	USB	1 x USB OTG 2 X USB 2.0 Host
	Ethernet	10/100/1000 Mbps
	Wireless	WIFI IEEE 802.11 a/b/g/n/ac Bluetooth Antenna
	Switch	Power Button
Power Input	DC	9V~24V

Absolute Maximum Ratings

Parameter	Symbol	Condition	Min	Max	Unit
Power Supply	VIN	-	-0.3	26.0	V
Operating Temperature(TS)	T_OP	-	0	+70	°C
Storage Temperature (TA)	T_ST	-	-30	+80	°C
Humidity	Hd	Ta=60°C	10	90	%RH

Electronical Characteristics

Item	Symbol	Condition	Min	Typ	Max	Unit
Power Supply Voltage	VIN	-	9	12	24	V
Power Supply Current	IIN1	VIN=12V	-	TBD	-	A
IO High-Level input voltage	VIH	-	0.7xVdd3v3	-	Vdd3v3+0.3	V
IO Low-Level input voltage	VIL	-	-0.3	-	0.3xvdd3v3	V
IO High-Level output voltage	VOH	-	-	-	3.6	V
IO Low-level output voltage	VOL	-	-0.3	-	-	V

Products specifications

Brand	Powertip
Size	10.1"
Resolution	1280x800
Active Area (mm)	216.96x135.60
Color	Full Color
CPU	i.MX8M 1.6GHz Quad-Core 64bit ARM Cortex-A53
Operating System	Android / Yocto
Power supply	12V
Display Interface	USB/LAN/WiFi/BT/Audio
View Angle	IPS
Sunlight Readable	High 601~1200cd/m²
Touch Panel	Capacitive
O. Temperature (°C)	0~70
Preferred - Not Preferred	Preferred
