HMA800480T030ZHR06

TFT 5" 800x480 with CTP (3mm Cover Glass, OCR Bonding), 850cd/m², Wide View Angle (IPS), MCU STM32H750 ARM Cortex M7 @480Mhz with 16MB SDRAM compatible with STM's TouchGFX development platform

DESCRIPTION

POWERTIP's Intelligent MCU TFT modules are a powerful and versatile solution for both developers and users. At ther heart of this module we have STMicroelectronics' MCU STM32H750 compatible with TouchGFX GUI development software. The abundant graphic design combined with Powertip TFT display brings intuitive application under different scenarios. The Mini Board is equipped with customizable I/O ports such as CAN bus, Ethernet port or SD card slot.

Main features:

1) 5" Industrial grade TFT-LCD High Brightness panel with 3mm Cover Glass and OCR bonding

2) STM32H750 Mini Board with multi I/O ports: UART, SPI, I2C, CAN, Ethernet, USB, MicroSD, GPIO



1) 5" Industrial grade TFT







2) STM32H750 Mini Board







Contact us at [email protected] to have the Sample Project file to speed up your development!

SKU: HMA800480T030ZHR06
Brand: Powertip
Available: No
Accessory Kit
Price Breaks
Quantity
1+
5+
10+
Price
€97.60
€94.40
€88.70

For quantities above 25 pcs pls send your enquiry to [email protected] or call +39 0332 1888005

€97.60 excl tax

DESCRIPTION

POWERTIP's Intelligent MCU TFT modules are a powerful and versatile solution for both developers and users. At ther heart of this module we have STMicroelectronics' MCU STM32H750 compatible with TouchGFX GUI development software. The abundant graphic design combined with Powertip TFT display brings intuitive application under different scenarios. The Mini Board is equipped with customizable I/O ports such as CAN bus, Ethernet port or SD card slot.

Main features:

1) 5" Industrial grade TFT-LCD High Brightness panel with 3mm Cover Glass and OCR bonding

2) STM32H750 Mini Board with multi I/O ports: UART, SPI, I2C, CAN, Ethernet, USB, MicroSD, GPIO



1) 5" Industrial grade TFT







2) STM32H750 Mini Board







Contact us at [email protected] to have the Sample Project file to speed up your development!

Products specifications
Brand Powertip
Size 5"
Resolution 800x480
Viewing Area (mm) 109.00x65.8
Active Area (mm) 108.00x64.80
Color Full Color
Power supply 5V
Display Interface UART // CAN // SPI // I2C // USB2.0 // MicroSD
Display IC STM32H750
View Angle IPS
Sunlight Readable High 601~1200cd/m²
Touch Panel Capacitive (Optical Bonding)
O. Temperature (°C) -20~70
Preferred - Not Preferred Preferred
Download
Products specifications
Brand Powertip
Size 5"
Resolution 800x480
Viewing Area (mm) 109.00x65.8
Active Area (mm) 108.00x64.80
Color Full Color
Power supply 5V
Display Interface UART // CAN // SPI // I2C // USB2.0 // MicroSD
Display IC STM32H750
View Angle IPS
Sunlight Readable High 601~1200cd/m²
Touch Panel Capacitive (Optical Bonding)
O. Temperature (°C) -20~70
Preferred - Not Preferred Preferred
