DESCRIPTION
The high-performance RYAGN3I active GPS and Glonass antenna with integrated low-noise amplifier (LNA) is the perfect match to any GPS and Glonass receivers where high sensitivity and optimum sky coverage are essential.
◆ Built-in low noise amplifier with 20dB gain and 0.65dB noise figure.
◆ 3M coaxial cable.
◆ Magnetic base suitable for mounting on car roof.
◆ Industrial temperature range: –40° C to +85° C.
◆ Wide range of supply voltage: +2.7 to 3.4 V.
◆ Low power consumption (3.6mA).
◆ Variable connector and cable length are available.
◆ 2KV HBM ESD Protection(including AI-pin).
SPECIFICATION
| Item |
Min. |
Typical |
Max. |
Unit |
Condition |
| Operation Voltage |
2.7 |
3.3 |
3.4 |
V |
|
| Current |
|
3.6 |
|
mA |
|
| Center Frequency |
1575.42 |
|
1602 |
MHz |
GPS and Glonass |
| Bandwidth |
|
10 |
|
MHz |
@S11=-10dB |
| Antenna Impedance |
|
50 |
|
Ω |
|
| Polarization |
|
|
|
|
R.H.C.P |
| Gain |
|
20 |
|
dB |
|
| Noise Figure |
|
0.65 |
|
dB |
|
| VSWR |
|
|
2 |
|
|
| Axial Ratio |
|
|
3 |
dB |
|
| Cable |
|
3 |
|
M |
RG174 Standard |
| Operating Temperature |
-40 |
25 |
+85 |
˚C |
|
| Body Dimensions |
|
|
|
|
45.5*34.2*15mm |
| Waterproof Level |
|
|
|
|
IEC/EN 60529 IPx8 |
| Mounting |
|
|
|
|
Magnetic base |
| Housing color |
|
|
|
|
Black |
| Antenna |
|
|
|
|
External |
