    HIA128800T004ZZC06

    TFT 10.1" 1280x800, High Brightness 800 cd/m², IPS, with CTP Embedded Display Kit - i.MX8M 1.6GHz Quad-Core 64bit ARM Cortex-A53, Memory LPDDR4 2GB, Android/Yocto OS, Multiple interfaces, WiFI & BT Module
    Brand: Powertip
    Cod.: HIA128800T004ZZC06
    Prezzi per quantità
    Quantità
    1+
    5+
    10+
    Prezzo
    €316,50
    €284,80
    €267,70

    Per quantità maggiori di 24pz prego invii la richiesta a [email protected] o chiami il +39 0332 1888005

    Disponibilità: Disponibile
    €316,50 IVA esclusa
    i h

    DESCRIPTION

    POWERTIP's Embedded MPU display kits are the go-to solution to implement Human Machine Interface (HMI) applications. With multiple peripheral interfaces (I2C, UART, SPI, USB2.0, PWM, I2S, etc.), hardware video decoding capability and both Linux or Android OS support any customer requirement can be met. We provide Board Support Packages (BSP) in order to help customers build their own root file system and accelerate development on the embedded system conveniently for their HMI solutions.

    This Embedded Kit consits of:

    1) System on Module (SoM)

    2) Multi-interface CARRIER BOARD

    3) 10.1" Industrial grade TFT-LCD High Brightness panel

    4) Connection accessories



    1. SYSTEM ON MODULE - SoM TYPE-1







    2. CARRIER BOARD







    3. TFT-LCD







    Contact us at [email protected] to have the Board Support Package (BSP) and user guide needed to install your preferred OS. We can also supply pre-built image files to speed up your development!

    Specifiche di prodotto
    Size 10.1"
    Resolution 1280x800
    Active Area (mm) 216.96x135.60
    Color Full Color
    CPU i.MX8M 1.6GHz Quad-Core 64bit ARM Cortex-A53
    Operating System Android / Yocto
    Power supply 12V
    Sunlight Readable High 601~1200cd/m²
    Touch Panel Capacitive
    O. Temperature (°C) -20~70
    In the Box SoM TYPE-1 + CARRIER BOARD + TFT Panel + LVDS Cable + CTP Cable
    Preferred - Not Preferred Preferred
    *
    *
    *
    *
