NT101-R001DW

Immagine di NT101-R001DW

Immagine di NT101-R001DW

Immagine di NT101-R001DW

TFT 10.1" 1024x600 LCD Panel, Interface RGB, 150cd/m², Wide View Angle (IPS), Resistive Touch Panel

General Specification

Color	16.7M
LCD Type	IPS-TFT-LCD
Viewing Angle	Wide viewing angle, 85/85/85/85(L/R/U/D)
Display Area(A.A)	222.72(W)*125.28(H)
Driver IC	ILI6150&ILI5120
Luminance	150cd/m²
LED Numbers	42 LEDS
Interface	RGB_24bit 50PIN_0.5mm

Electrical Characteristics

Digital Supply Voltage	3.3V(Typ.)
Voltage for LED Backlight	9.9V(Typ.)
Current for LED Backlight	280mA
LED Life-Time	30000 Hr

Optical Characteristics

Contrast Ratio	800:1
Color Gamut	53%
Color Temperature	10300K
Uniformity(with L/G)	80%

Touch Parameters Specification

Feature	Description
Type	RTP (Resistive touch panel)
Structure	ITO Film + ITO Glass + FPR
Outline Size (mm)	235.0(L)143.0(W)1.5(T)
Active Area (mm)	223.1(L)*125.7(W)
Life	Dot>1,000,000; Stroke>100,00
Surface Hardness	3H
Light Transmittance	78%±3
Operating Temperature	-20~70°C
Storage Temperature	-30~80°C

DRAWING

SKU: NT101-R001DW

Brand: Next Vision Display

Disponibile: Si

Si tratta dela prima recensione per questo prodotto

Kit Accessori

Display Connector
Touch-Panel Connector

Prezzi per quantità

Quantità

1+

5+

10+

Prezzo

€54,30

€48,40

€44,50

Per quantita’ maggiori di 25pz prego invii la richiesta a [email protected] o chiami il +39 0332 1888005

€54,30 IVA esclusa

Overview
Specifiche
Download
Contattaci

General Specification

Color	16.7M
LCD Type	IPS-TFT-LCD
Viewing Angle	Wide viewing angle, 85/85/85/85(L/R/U/D)
Display Area(A.A)	222.72(W)*125.28(H)
Driver IC	ILI6150&ILI5120
Luminance	150cd/m²
LED Numbers	42 LEDS
Interface	RGB_24bit 50PIN_0.5mm

Electrical Characteristics

Digital Supply Voltage	3.3V(Typ.)
Voltage for LED Backlight	9.9V(Typ.)
Current for LED Backlight	280mA
LED Life-Time	30000 Hr

Optical Characteristics

Contrast Ratio	800:1
Color Gamut	53%
Color Temperature	10300K
Uniformity(with L/G)	80%

Touch Parameters Specification

Feature	Description
Type	RTP (Resistive touch panel)
Structure	ITO Film + ITO Glass + FPR
Outline Size (mm)	235.0(L)143.0(W)1.5(T)
Active Area (mm)	223.1(L)*125.7(W)
Life	Dot>1,000,000; Stroke>100,00
Surface Hardness	3H
Light Transmittance	78%±3
Operating Temperature	-20~70°C
Storage Temperature	-30~80°C

DRAWING

Specifiche di prodotto

Brand	Next Vision Display
Size	10.1"
Risoluzione	1024x600
Area Attiva (mm)	222.72x125.28
Colore	Full Color
Interfaccia Display	RGB
Display IC	No
Angolo Visione	IPS
Frame	No
Touch Panel	Resistive
Temperatura O. (°C)	-20~70
Connessione Display	FPC for ZIF Connector
Nr. Pin	50
Passo Pin	0.5mm
Preferred - Not Preferred	Preferred

Download

Esegui il Login o Registrati per poter visualizzare PDF.

Nome completo

La tua email

Richiesta

Specifiche di prodotto

Brand	Next Vision Display
Size	10.1"
Risoluzione	1024x600
Area Attiva (mm)	222.72x125.28
Colore	Full Color
Interfaccia Display	RGB
Display IC	No
Angolo Visione	IPS
Frame	No
Touch Panel	Resistive
Temperatura O. (°C)	-20~70
Connessione Display	FPC for ZIF Connector
Nr. Pin	50
Passo Pin	0.5mm
Preferred - Not Preferred	Preferred
