    TFT 5" 720x1280 Portrait LCD Panel, Interface MIPI DSI IC ILI9881H, 300cd/m², Wide View Angle (IPS), Incell Capacitive Touch I2C Interface
    Cod.: NT050-C001DW

    Kit accessori

    Prezzi per quantità
    Quantità
    1+
    5+
    10+
    Prezzo
    €35,40
    €31,80
    €29,90

    Per quantità maggiori di 24pz prego invii la richiesta a [email protected] o chiami il +39 0332 1888005

    Disponibilità: Disponibile
    €35,40 IVA esclusa
    i h

    General Specification

    Color 16.7M
    LCD Type IPS-TFT-LCD
    Viewing Angle Wide viewing angle, 85/85/85/85(L/R/U/D)
    Display Area(A.A) 62.10(W)*110.40(H)
    Driver IC ILI9881H
    Luminance 300cd/m²
    LED Numbers 12 LEDS
    Interface MIPI 40PIN_0.5mm
    CTP Structure Incell(Without Cover Lens)
    CTP Interface IIC



    Electrical Characteristics

    Voltage for LED Backlight 9.6V(Typ.)
    Current for LED Backlight 80mA
    Backlight Power Consumption 768mW
    LED Life-Time 20000 Hr



    Optical Characteristics

    Contrast Ratio 900:1
    Color Gamut 70%
    Response Time 30ms
    Uniformity 80%





    DRAWING

    Specifiche di prodotto
    Size 5"
    Resolution 720x1280
    Active Area (mm) 62.10x110.40
    Color Full Color
    Display Interface MIPI
    Display IC ILI9881H
    View Angle IPS
    Frame No
    Touch Panel Capacitive
    O. Temperature (°C) -20~70
    Data Connection FPC for ZIF Connector
    Pin Nr. 40
    Pin Pitch 0.5mm
    Preferred - Not Preferred Preferred
